HGL Series
General Purpose AGM Batteries
HGL Series is a true dual-purpose battery. Like all of the batteries in the Fullriver line-up, HGL is designed to meet the highest standards. The batteries incorporate thick-plates of pure virgin lead (99.994%), in a tough case with zero chance of leaks or spills. For use in almost any application, the battery pairs well with dual-purpose needs like Marine and RV.
| Model | Voltage | 20HR 1.75 V/Cell Ah | 10HR 1.75 V/Cell Ah | Length mm | Width mm | Height mm | Total Height mm | Weight (Approx.) kg | Terminal |
| HGL20-6 | 6-Volt | 20 | 18.6 | 157 | 83 | 125 | 125 | 4.45 | M5 |
| HGL5-12 | 12-Volt | 5 | 4.65 | 90 | 70 | 101 | 107 | 1.48 | F1 |
| HGL7.2-12 | 12-Volt | 7.2 | 6.8 | 151 | 65 | 95 | 101 | 2.3 | F1 |
| HGL12-12 | 12-Volt | 12 | 11.2 | 151 | 99 | 95 | 101 | 3.75 | F1 |
| HGL18-12 | 12-Volt | 18 | 16.7 | 181 | 77 | 167 | 167 | 5.5 | M5 |
| HGL22-12 | 12-Volt | 22 | 20.5 | 181 | 77 | 167 | 167 | 6.05 | M5 |
| HGL26-12 | 12-Volt | 26 | 24.2 | 165 | 176 | 125 | 125 | 7.8 | M6 |
| HGL28-12 | 12-Volt | 28 | 26 | 166 | 126 | 174 | 174 | 8.6 | M5 |
| HGL35-12 | 12-Volt | 35 | 32.6 | 196 | 131 | 155 | 167 | 10.3 | M6 |
| HGL40-12 | 12-Volt | 40 | 37.2 | 198 | 166 | 174 | 174 | 13.4 | M6 |
| HGL45-12 | 12-Volt | 45 | 41.9 | 198 | 166 | 174 | 174 | 13.5 | M6 |
| HGL55-12 | 12-Volt | 55 | 51.2 | 229 | 138 | 208 | 212 | 17.2 | M6 |
| HGL65-12 | 12-Volt | 65 | 61 | 351 | 167 | 176 | 176 | 21.2 | M6 |
| HGL70-12 | 12-Volt | 70 | 66.3 | 260 | 169 | 211 | 215 | 21.9 | M6 |
| HGL75-12 | 12-Volt | 75 | 70 | 260 | 169 | 211 | 215 | 23.1 | M6 |
| HGL90-12 | 12-Volt | 90 | 84 | 307 | 169 | 211 | 215 | 28.2 | M6 |
| HGL100-12A | 12-Volt | 100 | 93 | 328 | 172 | 214 | 220 | 30.4 | M8 |
| HGL100-12B | 12-Volt | 100 | 93 | 331 | 175 | 214 | 218 | 30.5 | M8 |
| HGL100-12C | 12-Volt | 100 | 93 | 307 | 169 | 211 | 215 | 30.6 | M6 |
| HGL120-12 | 12-Volt | 120 | 110 | 331 | 175 | 214 | 218 | 32 | M8 |
| HGL140-12 | 12-Volt | 140 | 130 | 341 | 173 | 281 | 287 | 42.5 | M8 |
| HGL160-12 | 12-Volt | 160 | 149 | 484 | 171 | 241 | 241 | 45.7 | M8 |
| HGL180-12 | 12-Volt | 180 | 167 | 530 | 209 | 214 | 218 | 55.3 | M8 |
| HGL200-12A | 12-Volt | 200 | 186 | 530 | 209 | 214 | 218 | 57.6 | M8 |
| HGL200-12B | 12-Volt | 200 | 186 | 522 | 242 | 218 | 222 | 59.8 | M8 |
| HGL210-12 | 12-Volt | 210 | 195 | 522 | 242 | 218 | 222 | 61 | M8 |
| HGL230-12 | 12-Volt | 230 | 214 | 522 | 242 | 218 | 222 | 64.5 | M8 |
| HGL240-12 | 12-Volt | 240 | 223 | 520 | 269 | 204 | 208 | 70.2 | M8 |
| HGL260-12 | 12-Volt | 260 | 242 | 521 | 269 | 220 | 224 | 75.2 | M8 |
