DC90-12
Deep-Cycle AGM Batteries
DC SERIES BATTERY SPECS
Weight(Kg) | 28.8 Kg |
Dimensions(mm) | 307×169×211×215 mm |
Group Size | 27 |
Voltage | 12-Volt |
CCA | 530 A |
CA or MCA | 630 A |
Capacity @ 5hr Rate | 74.0 AH |
Capacity @ 20hr Rate | 90.0 AH |
Capacity @ 72hr Rate | 95.5 AH |
Capacity @ 100hr Rate | 99.0 AH |
Reserve Capacity @ 25 Amps | 140 minutes |
Reserve Capacity @ 75 Amps | 38 minutes |
Internal Resistance(mΩ) | 4.20 mΩ |
Case Type | ABS Plastic - |
Terminal Type | M6 |
